Quilter

Quilter

Verified
4.1
15 saves
Updated November 3, 2026

Turns finished schematics into physics-checked PCB layouts for hardware engineers.

Key Takeaways

What it is
Turns finished schematics into physics-checked PCB layouts for hardware engineers.
Pricing
Freemium
Best for
  • Autonomous Placement and Routing
  • Physics Rule Checks
  • Candidate Reviewer
Rating
4.1/5

What is Quilter?

Quilter turns a completed schematic and board outline into multiple PCB placement and routing candidates. Its physics-driven AI checks electrical and manufacturing constraints while it works, then returns layouts in native formats for Altium, Cadence Allegro and OrCAD, Siemens Xpedition, or KiCad. It is aimed at electrical engineers, PCB designers, and hardware teams that need fabrication-ready boards faster.

Unlike a standard auto-router, Quilter treats component placement, stackup, and routing as one connected problem. It generates dozens or hundreds of candidates, ranks them against physics and fabrication rules, and shows the checks behind each result.

Quilter fits teams that already have a schematic and an ECAD workflow but need more layout capacity. It does not generate schematics, replace engineering review, or handle every board type. RF, blind/buried-via, and other advanced capabilities may be limited or in development, while users can pre-route high-voltage sections before upload. Its strongest use is accelerating routine and validation-board layout while engineers remain responsible for the final design.

Who is Using Quilter?

R&D Managers

Board bring-up moves faster when layout bottlenecks no longer control the prototype schedule.

PCB Designers

Multiple candidates provide a starting point for review, cleanup, and final signoff in the team's existing ECAD tool.

Electrical Engineers

Schematic owners can move into architecture, bring-up, and validation while Quilter handles much of the layout work.

Product Managers

Faster board turnaround gives hardware programs more room for testing and design iterations before a milestone.

MLOps and Infrastructure Engineers

Self-hosted deployments fit teams that need to run Quilter inside their own cloud or controlled network.

Uncommon Use Cases

Environmental test fixtures and harness boards; rapid derivative boards for semiconductor evaluation and validation

Key Features

Autonomous Placement and Routing: Quilter generates complete PCB layout candidates from your schematic, board outline, and design constraints.
Physics Rule Checks: Each candidate is evaluated with physics and DRC checks; length matching is still in development.
Candidate Reviewer: Quilter generates multiple layout candidates for engineer review and adjustment.
Native ECAD Outputs: Completed candidates return to Altium, Cadence Allegro and OrCAD, Siemens Xpedition, or KiCad in their native file formats.
Constraint-Aware Design: Schematics, board outlines, fixed components, stackups, constraints, and circuit intent guide the generated layout.
Iterative Design Review: Review a candidate in your ECAD tool, make adjustments, and resubmit through multiple layout cycles.

Rating Breakdown

4.1/ 5.0
accuracy
4.3
ease of use
4.0
features
4.5
speed
4.2
support
3.8
value
3.8

Pricing Plans

Popular

Free Tier

Free

  • Unlimited design iterations and all Quilter product features
  • For personal, academic, and eligible professional exploratory use
  • Public-cloud deployment with encryption in transit and at rest
  • Documentation and engineer-moderated community support
  • Designs may be used to generate synthetic training data
  • Eligibility includes fewer than 10 people or less than $50K in annual revenue

Enterprise

  • Commercial, professional, and business use
  • Public cloud, private cloud, on-premises, or air-gapped deployment
  • Designs are confidential and are not used for direct or indirect training
  • Unlimited iterations, team and site management, and custom integrations
  • Pricing scales with unrouted pin count rather than seats
  • Expert support with custom SLA options and dedicated technical account management

Which Quilter plan should you pick?

Start with Free Tier for personal, academic, or eligible exploratory work, then move to Enterprise when commercial IP protection, private deployment, team management, or enterprise support matters.

Free Tier

Good for students, researchers, hobbyists, and qualifying small teams evaluating automated PCB layout on non-sensitive designs.

Enterprise

Good for commercial engineering teams that need confidential designs, private or self-hosted deployment, custom integrations, and SLA-backed support.

Quilter Use Cases

Test and Validation Boards

Short-cycle hardware programs can move from schematic to routed candidates without waiting for a central layout team.

Outcome: Faster board bring-up and earlier firmware or system testing.

Semiconductor Evaluation Boards

Evaluation and bring-up teams get multiple layout options for boards tied to silicon validation schedules.

Outcome: Candidates can appear within the first hour, with bring-up-ready work targeted for a single workday.

Environmental Test Fixtures

Fixture and harness designs benefit from automated placement, routing, and constraint checks when layout capacity is limited.

Outcome: Shorter layout cycles and fewer delays to qualification testing.

Derivative Board Design

Existing designs can be adapted into new board variants while Quilter handles routine placement and routing work.

Outcome: More board variants can be explored with the same engineering team.

Production Layout Assistance

Teams can use Quilter for suitable portions of larger designs while engineers pre-route critical sections such as RF nets or BGA fanouts.

Outcome: Routine sections move faster while specialists retain control of sensitive areas.

Workflow Ideas with Quilter

From Schematic to Candidate

  1. 1Finish and validate the schematic in Altium, KiCad, Cadence Allegro, or Siemens Xpedition.
  2. 2Prepare the board outline, footprints, netlist, mounting holes, and fixed components.
  3. 3Upload the files, review generated candidates, and download the strongest layout for ECAD cleanup.

Constraint-Led Board Iteration

  1. 1Set the stackup, DRC rules, net classes, placement regions, and key circuit constraints.
  2. 2Run Quilter to generate and rank multiple placement and routing candidates.
  3. 3Adjust the preferred result in ECAD, then resubmit for another design cycle.

Critical-Section Hybrid Flow

  1. 1Pre-route RF nets, BGA fanouts, high-voltage traces, or other sections requiring specialist control.
  2. 2Submit the remaining unrouted board sections to Quilter.
  3. 3Review the returned layout and finish final DFM, DRC, and engineering checks in ECAD.

How Quilter fits into your stack

Existing ECAD Tools

Quilter sits after schematic and initial board preparation in Altium, KiCad, Cadence Allegro, or Siemens Xpedition. It returns candidates to the same native design environment.

PCB Constraints

Stackups, DRC rules, net classes, placement regions, differential pairs, and power nets give the AI the information needed to make layout decisions.

Engineering Review

The generated board is a review input, not a replacement for signoff. Engineers inspect candidates, clean up the design, run their own DFM checks, and approve the final output.

Cloud and Private Infrastructure

Teams can use the hosted service or deploy Quilter in AWS, GCP, Azure, a private cloud, an on-premises environment, or an air-gapped network.

Manufacturing Handoff

Physics and fabrication checks help rank candidates before the design returns to the normal release and fabrication process.

Pros

  • +Physics-based placement: Evaluates placement and routing together instead of treating placement as fixed.
  • +Native ECAD workflow: Returns candidates for Altium, Cadence, Siemens Xpedition, and KiCad.
  • +Free personal tier: Offers unlimited iterations for personal, academic, and eligible exploratory professional work.
  • +Flexible deployment: Enterprise teams can use public cloud, private cloud, on-premises, or air-gapped environments.
  • +No per-seat model: Enterprise pricing is based on unrouted pin count rather than named seats.

Cons

  • −Narrow scope: Quilter handles PCB layout, not schematic creation or broad circuit simulation.
  • −Board fit matters: RF-heavy, high-voltage, and very high-density HDI designs are not current strengths.
  • −Commercial pricing is quote-based: Teams cannot compare an enterprise plan through a public dollar price.

Limitations & when to consider alternatives

Known limitations

  • Complete schematic required. Quilter handles layout only, so the schematic must already be designed and validated in a supported ECAD format.
  • Unsupported symmetrical multi-channel layout. Quilter can parse hierarchical schematics but does not currently support symmetrical layout for multi-channel designs.
  • Board-type constraints. The current fit is strongest for low-voltage, low-current, low-to-medium-density boards. RF-dominant, high-voltage, and very high-density HDI designs are not current fits.
  • Free-tier data use. Designs uploaded to the free tier may be parsed to generate synthetic training data. Enterprise designs are not used for training.
  • Final engineering work remains. Users still need to review candidates, finish remaining unrouted nets, address flagged DRC issues, run their own DFM checks, and apply internal design standards.

Look elsewhere when

  • You need an AI tool that generates schematics or performs broad circuit simulation.
  • Your board is dominated by RF, high voltage, or very high-density HDI requirements.
  • Your team wants a public, self-serve commercial price instead of a quote-based enterprise plan.
  • You need a native mobile or desktop design application.

How to Use Quilter

  1. 1

    Prepare the ECAD files

    Start with a complete schematic and a linked board file containing the outline, footprints, and netlist.

  2. 2

    Set the design context

    Add fixed mechanical components, stackup details, DRC rules, net classes, and placement regions so the AI understands the board's constraints.

  3. 3

    Submit the layout job

    Upload the supported files and let Quilter generate placement and routing candidates.

  4. 4

    Review the candidates

    Compare routing completion, DRC results, physics checks, layer count, trace rules, and fabrication fit.

  5. 5

    Return to ECAD

    Download a candidate in the native format, make engineering adjustments, and complete your team's DFM and release checks.

  6. 6

    Iterate or deploy privately

    Resubmit revised designs for additional candidates, or choose an enterprise private-cloud, on-premises, or air-gapped deployment for protected work.

Who is Quilter For?

PCB Designers

Useful when you need to explore many placement and routing options without hand-building each version.

Electrical Engineers

Helpful for moving from a finished schematic to a reviewable board while keeping control of constraints and revisions.

R&D Hardware Teams

Fits teams whose prototype schedules are slowed by layout queues and limited board-design capacity.

Semiconductor and Robotics Teams

Supports fast-turn test, evaluation, and validation boards that need to reach bring-up quickly.

Aerospace and Defense Teams

Enterprise deployment options support teams with stricter data residency, security, and infrastructure requirements.

Frequently Asked Questions

Is Quilter free?

Yes. The Free Tier is available for personal, academic, and eligible professional exploratory use, with unlimited design iterations and all Quilter product features.

What does the free tier allow?

It supports private data on Quilter's public cloud and includes documentation and community support. Designs submitted to the free tier may be used to generate synthetic training data.

How is enterprise pricing calculated?

Pricing scales with unrouted pin count rather than seats. Iterations within a project are unlimited, and production-program pricing requires contact with Quilter.

Which ECAD tools does Quilter support?

Quilter supports Altium, KiCad, Cadence Allegro, and Siemens Xpedition, returning completed candidates in native file formats.

Can Quilter run in a private environment?

Yes. Enterprise customers can use private cloud, on-premises, self-hosted, or air-gapped deployment options.

Does Quilter train on customer designs?

Enterprise designs are not used for training, and enterprise jobs are processed in isolation. The free tier may use board metadata or input files to generate synthetic training data.
